Gas Steam Boilers
-
ZH-100G
Product Name：
Gas Steam Boilers
Product Number：
ZH-100G
Product Category：
Steam produced within 4-5 mins after ignition
Stable steam quality
Efficient Heat Transfer
Licence-free & inspection-free
Efficiency 98.5%
Silent operation
Safety device control
High technology, high quality
Facebook
Email
WhatsApp
| MODEL | ZH-100G | ||||
|---|---|---|---|---|---|
| PERFORMANCE | EQUIVALENT OUTPUT | kg/h | 100 | ||
| HEAT OUTPUT | kcal/h | 53900 | |||
| HEATING SURFACE AREA | m² | 2.8 | |||
| MAX. PRESSURE | kgf/cm² | 10 | |||
| WATER CONTENT | L | 33 | |||
| BOILER EFFICIENCY | % | 88 | |||
| WATER PREHEATER | － | N | |||
| COMBUSTION TYPE | － | ON-OFF | |||
| FUEL CONSUMPTION |
NG | 13A | Nm³/h | 6.2 | |
| LPG | PROPANE | kg/h | 5.3 | ||
| BUTANE | 5.6 | ||||
| ELECTRICAL POWER CAPACITY | kw | 1.1 | |||
| POWER OF AUXILIARY EQUIPMENT |
WATER PUMP MOTOR | kw | 0.4 | ||
| EXHAUSTING FAN MOTOR | 0.4 | ||||
| CONTROL PANEL | 0.3 | ||||
| PRODUCT WEIGHT | kg | 3650 | |||
| PIPE DIAMETERS |
GAS INLET DIA | 13A | mm | 20 | |
| LPG | 15 | ||||
| FEED WATER INLET DIA | 15 | ||||
| STEAM OUTLET DIA | 20 | ||||
| BOILER-WATER DRAIN DIA | 25 | ||||
| SAFETY VALVE DIA | 25 | ||||
| AUTO BLOWDOWN DIA | / | ||||
| CHIMNEY DIA | ømm | 150 | |||
| POWER WIRE INLET DIA | mm² | 2.0 | |||
| SIZE | BOILER DIMENSIONS | LENGTH | mm | 1020 | |
| WIDTH | 711 | ||||
| HEIGHT | 1550 | ||||
